Power Requirements:
220 VAC, 3 Phase 20 AMP, 50/60 HZ, grounded. |
Media Throwing Wheel:
4" Diameter with speed range to 20,000 RPM for high velocity
impact. Motor is an Electric Brushless/DC, with Direct Drive hook-up
and matching Controller Board. |
Parts Basket:
(Stainless Steel)
SB-12 = 12" dia. x 12" deep
SB-16 = 16" dia. x 16" deep
Perforation is 0.250 Ø standard |
Refrigerant:
Liquid Nitrogen at -320º F. at 50 PSIG maximum. |
Media/Flash Separator:
Housed in the lower compartment for separating media, flash and
fine particles. |
Processor Controls:
Programmable micro-processing computer with 9999 processing programs.
All applicable functions displayed on the color monitor with
bar code reader system. |
Media Flow System:
Gaseous Nitrogen or Clean/Dry Shop Air (30/35 PSIG) |
Media Type:
System can operate utilizing any plastic blast media. |
Insulation:
2" Thick rigid, high density polyurethane foam for cold containment
around inner blast chamber. |
Gaseous Nitrogen:
Using an ambient vaporizer (500 scfh) to create GN
2
for the media assist system. |
|
|
